Waterproof Police Worn Cameras Ambarella H22 CMOS 4MP OV4689 HD Body Camera
Product Details:
| Place of Origin: | Shenzhen |
| Brand Name: | Oxiang /OEM |
| Certification: | CE.RoHS,FCC |
| Model Number: | ZP516P |
|
Detail Information |
|||
| AES256 Encryption: | Support | LCD Screen: | N/A |
|---|---|---|---|
| Waterproof: | IP67 | View Angle: | 140° |
| Video Transfer: | USB 2.0 Type C | Dimension: | 81.5*58*23.7mm /140g |
| Highlight: | Waterproof Police Worn Cameras,4MP OV4689 Police Worn Cameras,Ambarella H22 HD Body Camera |
||
Product Description
HD Body Camera Ambarella CMOS Sensor 4MP Waterproof Dual Band
Parameter
| HARDWARE | |
| Chipset | Ambarella H22 |
| CMOS Sensor | 4MP OV4689 |
| Lens | 140-degree Wide Angle |
| Screen | No Screen |
| Storage | Built-in 32GB/64GB/128GB |
| Battery | Built-in 3200mAH Lithium-Polymer Battery |
| Weight | Camera: 141g Clip: 21g |
| Size | 81.5*58*23.7 mm (H*W*D) |
| IP Rating | IP67 |
| WiFi | Built-in |
| Infrared LED | Up to 15 Meters Working Range |
| Auto IR | YES, Support Night Vision, 2 Infrared lights |
| Drop-in Dock | YES |
| APP | Compatible with IOS and Andriod |
| Interface | USB Type C Port in Camera |
| Buttons | 3 |
| Indicators | 3pcs, Separate Battery Status Indicator |
| Front Recording Button | YES |
| Shock Proof | 1.8m (5.9ft) |
| BATTERY PERFORMANCE | |
| Contineously Recording Time (Single Battery) |
12 hours at 1080P @30fps; |
| 15 hours at 480P @30fps; | |
| Low Battery Warning | Beep Alert |
| Charging Time | 4 hours |
| ONVIF | Support ONVIF streaming & recording Support NVR brand such as Hikvision, Dahua, Uniview and so on |
| EIS | Support 6-Axis Electronic Image Stablization |
| Working Temperature | -30~+55 Degrees Celsius |
| Storage Temperature | -40~+60 Degrees Celsius |
| VIDEO | |
| Video Format | .MP4 (Video Coding: H.265/H.264) |
| Camera Video Resolution | 1920x1080p@30fps; 1280x720@30fps; 848x480@30fps |
| Streaming Video Resolution | 1280x720@30fps; 848x480@30fps; 432x240@30fps |
| Streaming Bitrate Control | YES |
| Image Resolution | 16M(5344x3000) 12M(4208x2592) 8M(3840x2160) 4M(2688x1512) |
Feature
Built-in Wifi (WIFI Mode:AP and STA; Dual Band:2.4G/5G);
Built-in 32G TFcard,With Dock Charger
Wifi APP: FN Cam; Wifi Name:bodycam； Password:12345678
1. Big Front video button, easy operation, especially when in winter time, officer wear gloves
2. Support AES256 encryption
3. Support Bluetooth 4.1
4. Ambarella A12 Chipset;CMOS Sensor 4MP OV4689
5. No LCD Screen
6.Video Format:H.264 MP4; Photo Format:JPG
7. Built-in 3200mAh battery, 10 hours at 1080P @30fps;12 hours at 480P @30fps
8. Video Resolution1920x1080p@30fps; 1280x720@30fps; 848x480@30fps;Streaming Resolution:1280x720@30fps; 848x480@30fps; 432x240@30fps
9. Photo resolution: 4M / 8M / 12M / 16M/ 32M/ 40M
10. 140° field of view
11. Storage Capacity:Support 16G/32G/64G/128G
12. 2 Infrared LED Up to 15 Meters Working Range
13. Water Mark :User ID, Time and date Stamp,GPS coordinates Imbedded into Video.
14.IP Rating:IP67 & 2 meters shock-proof
15.Password protect:To set an administrator password to allow deletion via software.User can only view the videos but cannot delete it.
16. Video Transfer: USB 2.0 Type C
17.Support Take picture while video recording
18. Pre-record 60-120 Seconds;Post-record 5/10/20/30/60 Seconds
Dimension:81.5*58*23.7mm /140g
Function
