4G Thermal Imaging Split Helmet Police Worn Cameras Temperature Measurement
Product Details:
| Place of Origin: | China |
| Brand Name: | OEM |
| Certification: | CE/FCC |
| Model Number: | OX-ZP630T |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | USD2000.0-USD2900.0/pcs |
| Packaging Details: | 50*45*36cm |
| Delivery Time: | 5-8 work days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 100000/Month |
|
Detail Information |
|||
| Operation System: | Android 7.1 | Pixel: | 320X240 |
|---|---|---|---|
| Thermal Sensitivity: | 0.1 Degree | Measuring Range: | -10 +330 Degrees |
| Angle Of Camera: | 70 ° | Photo: | 4MP JPEG Format |
| WiFi: | Support 802.11b/g Protocol，2.4GHZ | 3G/4G: | Support |
| Bluetooth: | BT4.0 | Frequecy Band: | TDD：B38 B39 B40 B41 FDD:B 1.3.5.8.4.7.28B |
| Highlight: | Temperature Measurement Police Worn Cameras,Split Helmet Police Worn Cameras,4G Thermal Imaging Police Shoulder Camera |
||
Product Description
4G thermal imaging temperature measurement split helmet Camera
-Parameters:
| Technical parameters | ||
|
thermal imaging parameters |
Uncooled infrared focal plane detection | |
| Pixel:320X240 | ||
| Viewing angle: 45-50 degrees 6.52mm f1.18 Minimum focal length: 0.5 meters | ||
| Thermal sensitivity: 0.1 degree | ||
| Frame rate: 9Hz; wavelength range: 8-14um | ||
| Measuring range: -10 +330 degrees | ||
| System | Operation system:Android 7.1 | |
| Processor:MTK6739 Quad-core ARM@Cortex-A53 MPCore | ||
| Visible Optics camera | Foucus range:0.5 Meters----Infinty | |
| Angle of camera:70 ° | ||
| Photo: 4MP JPEG format | ||
| Other details | Distance of night vision:The human faces can be seen at 10 Meters in a totally black environment | |
| Working time: standby more than 25h, camera work more than 5h | ||
| Waterproof:IP66 | ||
| Lithium battery :3600mAh | ||
| Video | Video coding resolution | 1080P/720P mp4 Format |
| Video FPS | 1080P@30fps /720@30fps | |
| Video bitrate | 256kbps-8Mbps | |
| Wireless connected | WiFi | Support 802.11b/g protocol,2.4GHZ |
| 3G/4G | Support | |
| Frequecy band | TDD:B38 B39 B40 B41 FDD:B 1.3.5.8.4.7.28B | |
| Bluetooth | BT4.0 | |
| Size | Weight | About 170g |
| Dimension | (L*W*H) 115*60*40mm | |
| Working temperature | -30°C to +70°C | |
| Management software | Real time play | support real-time 160 way data |
| Beidou/GPS | Same Smarteye screen can check up to 256 camera position tracking | |
| Data upload | support D1 H.264 data upload | |
| Wireless intercom: | Real time 4G network wireless intercom,Multi person meeting | |
| 4G upload:Real time uploaded function | ||
| Data of real time uploaded can be checked in the platform | ||
Our service
1. In the case of non-artificial damage, all products purchased in our company are guaranteed to keep one year
warranty and we have proceeded aging test before.
2. If quality problems happen in guarantee period, our company will maintain for free.
3. Additionally, our company provides technical support for life.
4. If you are caught in some problems when using our products, welcome to contact your relevant salesman at any time, we promise to make positive response within 12 hours.
5. After expiry of a guarantee period, we provide to repair for life, and our clients just need to pay parts original cost.
RFQ
1. Q: Are you a manufacturer or trading company?
A: We are a manufacturer who has been specializing in producing WIFI hidden cameras for 10 years.
2. Q: What is the minimum order?
A: Yes, our company mainly deals with wholesale deals, but if you insist buying one set, or you just need one set,
we would be very likely to make the MOQ as 1 set for you.
3. Q: When will you make the delivery?
A: Sample: 1-3 working days;
Bulk order: According to the quantities. If the number of products are 500-1000pcs, it will need about one week to
deliver. If the number is over 1000pcs and you have an immediate demand please contact us, we are online from
8.30 am to 21.00 pm, your questions or inquiry shall be respond within 12 hours at most.
4. Q: What kinds of trade term payment methods available ?
A: EXW, CIF, FOB.etc. Usually we accept T/T, West Union, Paypal, Alibaba payment.
5. Q: May I get free sample?
A: Normally, we will charge the samples to start the business. However, the sample fee is refundable when you
place bulk orders.
6. Q: Can you supply OEM or ODM service?
A: We can supply OEM/ODM service of any charger or power adapter absolutely!
7. Q: How to proceed the order if I have logo to print?
A: Firstly, we will prepare artwork for visual confirmation, and next we will produce a real sample for your second
confirmation. if mockup is ok, finally we will go to mass production.
